    ERAMOTOR : N-MAX

    YAMAHA N-MAX



    PRODUCT SPECIFICATION:
    Mesin
    Tipe Mesin : Liquid cooled 4 Stroke, SOHC
    Jumlah/Posisi SIlinder : Single Silinder
    Diameter X langkah : 58,00 mm X 58,7 mm
    Perbandingan kompresi : 10,5:1
    Daya Maksimum : 11,1 kw/8000 rpm
    Torsi Maksimum : 14,4 Nm/6000 rpm
    Sistem Starter : Elektrik Starter
    Sistem Pelumasan : Basah
    Kapasitas Oli Mesin : 1,00 L : Berkala=0,90 L
    Sistem Bahan Bakar : Fuel Injection
    Tipe Kopling : Kering, Centrifugal automatic
    Tipe Transmisi L : V-Belt Automatic

    Kelistrikan
    Sistem pengapian : TCI
    Baterai : YT27V
    Tipe Busi : NGK/CPR8EA-9

    Dimensi
    P X L X T : 1.955 mm X 740 mm X 1.115 mm
    Jarak sumbu roda : 1.2350 mm
    Jarak terendah ke tanah : 135 mm
    Tinggi tempat duduk : 765 mm
    Berat Isi : 127 kg
    Kapasitas tangki bensin : 6,61

    Rangka
    Tipe rangka : Underbone
    Suspensi depan : Teleskopik
    Suspensi belakang : Unti Swing
    Ukuran Ban depan : 110/70 – 13M/C 48P
    Ukuran Ban belakang : 130/70 – 13M/C 63P
    Rem Depan : Single disc brake (ABS)
    Rem belakang : Single disc brake (ABS)


    HARGA OTR JAKARTA N-MAX ABS RP 27.900.000,-

    HARGA OTR JAKARTA N-MAX NON ABS RP 23.500.000,-

    Untuk harga wilayah lain, dan harga lainnya bisa dilihat disini:
    http://www.modifikasi.com/showthread.php/613061-ERA-MOTOR-PRICE-LIST-2015



    ERA MOTOR

    HUB CONTACT CENTER kami :
    021-4216483 (hotline)
    082122746856 (SMS/WHATSAPP)
    57DA0BF4 (BBM)

    Kami siap membantu anda
