    THE NEW AMPLIFIERS REVOLUTIONARY from AUDIOSYSTEM !!!

    Introducing : THE NEW WORLD CLASS AMPLIFIERS "mosconi by AUDIOSYSTEM"

    ? DESIGN ? POWER ? EMOTION









    About us

    The brand “Mosconi” originated as a diversification for MOS company in the SBU car-audio market.
    Its history is still very short: at the end of 2008, Ivan Mosconi, driven by love for electronics and sound, brings together a team of designers and engineers with decades of experience in the professional audio sector and after a few months, in the summer of 2009, the first line of amplifiers branded Mosconi is already on the market: the AS series.
    Since 2006 MOS has been production, assembly, engineering and industrialization of products and electronic devices.
    MOS has a very simple philosophy: putting all its talent and experience in providing products and services that can help improve the everyday life of society, through a high aesthetic expression.
    Every day, the members of the MOS staff continue to strive towards this goal. We are dedicated to the constant pursuit of refining and improving our technologies so as to offer more efficient and intelligent products but without any compromise to our greatest strength: our unique and remarkable designs.



    AS Series

    We've really done a good job!
    We were all a bit sceptical about the ability of disposal of our heat-sink. We had been thinking of it for a while, but we had never actually tried. Then, one day Filippo, our technician, called us and said: “Incredible!” And it never goes into protection!, and I still haven’t even attached the 2nd heat sink (the extruded aluminum chassis)... “Well”- I answered - “And now make it produce an audiophile sound!” And Filippo did.
    When we started with the design of AS, everybody had something to say for the "model amplifier", firing all the "usual" key points:

    ? High quality sound.
    ? Maximum reliability for the most difficult installations.
    ? Ability to drive loads up to 1Ohm stereo.
    ? Compact dimensions.
    ? Top adjustment, intuitive and easily accessible.
    ? Connections completely covered and isolated by thermoplastic parts resistant to high temperature (those of the supply are huge!!!).
    ? Hidden mounting points for a neat installation.
    ? Simple and intuitive design.
    ? 100% made in Italy

    and, of course, a fair price and accessible to Sound Quality lovers.

    The usual strong points? Yes, but the difference is we've got them all in one amplifier.



    100% MADE IN ITALY


    MOSCONI AS series amplifiers are fully designed, developed and produced in Italy.
    More than that, MOS has created an "industrial district" within a radius of 100 km so we can be in control of every single step of the production and manufacturing process.
    This choice, which openly runs against the current trend of other competitors in the market, was desired and sought to ensure the assembly of electronic components is at the highest quality level and to qualify the uniqueness of the high quality design of mechanical parts in combination with the quality control of every working step.


    THE DESIGN

    The design is shaped on its function, with special care to hide every point of connection, from the smallest screw, to the controls and the cable plugs; on every single element that makes up the amplifier in its deepest essence, giving the products a sleek, sophisticated line while ensuring a clean, secure and enjoyable installation.


    THE SOUND

    Analogue signal processors used in strategic points of the amplification stage, contribute to the uniqueness of sound and timbre of MOSCONI AS series.
    The audio power stages and the DC/DC converter use exclusively AUTOMOTIVE MOSfet devices and provide high power supply coupled with high speed transient response.
    The pre amplifier circuitry has very low noise to eliminate hiss. The amplifier also has time delay turn on mute to prevent transient thumps. These are standard in the Mosconi design.


    THE STRENGTH


    MOSCONI AS series represents MOS commitment to the realization of amplifiers designed for the sound as well as for competitions and SPL
    The highest power, the high current and the impressive dynamics are the features of a project studied with attention to even the smallest details.
    The use of dedicated semiconductors, the distribution of power among parallel transformers and the adoption of a highly efficient system of heat dissipation provide all the strength, quality, versatility, control and reliability needed to drive loads down to 1 Ohm Stereo or 2 Ohm mono BTL.

    THE PROJECT


    The quality of the project MOSCONI AS series amplifiers, combines the highest criteria of design and efficiency.
    An accurate internal and external engineering provides great power, small size and high sound quality. The utmost attention has been paid to the realization of the amplifier, especially in the disposal of heat, the air flow circulation and the positioning of components.
    Every detail has been designed and built to perform their functions well.
    The heat-sink with its high efficiency is the result of meticulous planning which has allowed the creation of a very compact form which is also highly efficient from a thermal point of view.
    The use of large amounts of aluminium (7Kg/mt) and the forced air cooling, coupled with the dynamic controller fan ProSpeed®, ensure top performance.
    The wiring is secured by massive power connectors derived from solid blocks of metal, specially designed to handle the highest current demands. The power connectors can accommodate cables up to 0 awg.
    The PC board is of professional manufacturing being double-side layer with plated holes, made exclusively with the finest materials.
    In higher performing products such as AS300.2 and the AS200.4, portions of multilayer printed circuit board are used to ensure the least resistance to the passage of the large currents involved.
    A circuit called S.V.S. (Service Voltage Stabilizer) ensures the optimal functioning of all services in both amplifier and DC/DC converter, physically separating the performances of inside circuits from battery voltage fluctuation.
    Even in the design of the DC/DC converter, an advanced technology has been used for the elimination of electromagnetic interference, whose production and dissemination are also dramatically reduced in the electrical system of the car, thanks to it.

    THE CONTROL

    Each type of adjustment is easily accessible from the top side of the amplifier, which makes it very installation and setup friendly.
    Every single control is specifically positioned in a functional way, making the calibration simple and intuitive.
    The functions in the crossover section of MOSCONI AS series can cover a great variety of needs implementing a low-pass filter and a high-pass filter with the ability to connect the two filters cascaded to achieve a band-pass.
    Each amplifier has been equipped with an expansion "slot", to enable future upgrades to the amplifier. One of these, the remote volume control (RTC CARD), is already available.

    THE RELIABILITY

    There are numerous proprietary protections included to make the reliability of the MOSCONI AS series amplifiers at the highest levels and avoid possible damages due to improper installations.
    Protections by:

    ? Low current battery
    ? High frequency oscillation
    ? Bump while turning on
    ? Voltage on the chassis
    ? Voltage on the RCA
    ? Power outputs shorted to RCA
    ? Power outputs shorted to car chassis
    ? Output overload
    ? DC current through speakers
    ? Voltage difference between the grounds
    ? Excessive operating temperature

  2. Jaya Bet
  3. #2
    Letnan Dua
    Location
    www.cliport-audio.com
    Posts
    1,211
    Power
    M-Store Point
    0
    Online
    1 Wk 3 Days 18 Hrs 45 Mins 39 Secs

    Thumbs up Comming Soon: THE NEW AMPLIFIERS REVOLUTIONARY from AUDIOSYSTEM !!!

    AS65.2




    Technical Features

    Target Powers:

    ● 65 Watt per channel @ 4 Ohm
    ● 105 Watt per channel @ 2 Ohm
    ● 210 Watt BTL mode @ 4 Ohm

    Input sensitivity:
    (Power rating ref)
    ● 0.2 V ÷ 5 V

    Xover functions:
    (BAND Pass allowed)
    HIGH Pass & LOW Pass
    (20 ÷ 175 Hz) & (50 ÷ 30 0Hz)

    Filter slope - Filter "Q":
    ● 12 dB/oct - 0.7 (Stereo & Mono)

    Size:
    ● 215x200x50 mm

    Weight:

    ● 2 Kg
    AS100.2



    Technical Features


    Target Powers:
    ● 100 Watt per channel @ 4 Ohm
    ● 160 Watt per channel @ 2 Ohm
    ● 320 Watt BTL mode @ 4 Ohm
    ● 500 Watt BTL mode @ 2 Ohm*

    Input sensitivity:
    (Power rating ref)
    ● 0.2 V ÷ 5 V

    Xover functions:

    (BAND Pass allowed)
    HIGH Pass & LOW Pass
    (20 ÷ 175 Hz) & (50 ÷ 30 0Hz)

    Filter slope - Filter "Q":

    ● 12 dB/oct - 0.7 (Stereo & Mono)

    Size:
    ● 215x200x50 mm
    Weight: 2,2 Kg
    AS200.2




    Technical Features


    Target Powers:
    ● 200 Watt per channel @ 4 Ohm
    ● 320 Watt per channel @ 2 Ohm
    ● 640 Watt BTL mode @ 4 Ohm
    ● 1000 Watt BTL mode @ 2 Ohm*

    Input sensitivity:

    (Power rating ref)
    ● 0.2 V ÷ 5 V

    Xover functions:
    (BAND Pass allowed)
    HIGH Pass & LOW Pass
    (20 ÷ 175 Hz) & (50 ÷ 30 0Hz)

    Filter slope - Filter "Q":

    ● 12 dB/oct - 0.7 (Stereo & Mono)

    Size:
    ● 350x200x50 mm

    Weight:
    ● 3,5 Kg

  4. #3
    Letnan Dua
    Location
    www.cliport-audio.com
    Posts
    1,211
    Power
    M-Store Point
    0
    Online
    1 Wk 3 Days 18 Hrs 45 Mins 39 Secs
    AS300.2


    Technical Features

    Target Powers:
    ● 300 Watt per channel @ 4 Ohm
    ● 550 Watt per channel @ 2 Ohm
    ● 1100 Watt BTL mode @ 4 Ohm
    ● 1800 Watt BTL mode @ 2 Ohm*

    Input sensitivity:

    (Power rating ref)
    ● 0.2 V ÷ 5 V

    Xover functions:
    (BAND Pass allowed)
    HIGH Pass & LOW Pass
    (20 ÷ 175 Hz) & (50 ÷ 30 0Hz)

    Filter slope - Filter "Q":

    ● 12 dB/oct - 0.7 (Stereo & Mono)

    Size:
    ● 590x200x50 mm

    Weight:

    ● 5,8 Kg
    AS100.4



    Technical Features

    Target Powers:
    ● 100 Watt per channel @ 4 Ohm
    ● 155 Watt per channel @ 2 Ohm
    ● 310 Watt BTL mode @ 4 Ohm
    ● 480 Watt BTL mode @ 2 Ohm*

    Input sensitivity:
    (Power rating ref)
    0.2 V ÷ 5 V

    Xover functions:
    (BAND Pass allowed)
    HIGH Pass & LOW Pass
    (20 ÷ 175 Hz) & (50 ÷ 30 0Hz)

    Filter slope - Filter "Q":
    ● 12 dB/oct - 0.7 (Stereo & Mono)

    Size:
    350x200x50 mm

    Weight:

    ● 3,5 Kg
    AS200.4


    Technical Features


    Target Powers:
    ● 200 Watt per channel @ 4 Ohm
    ● 320 Watt per channel @ 2 Ohm
    ● 640 Watt BTL mode @ 4 Ohm
    ● 950 Watt BTL mode @ 2 Ohm*

    Input sensitivity:

    (Power rating ref)
    ● 0.2 V ÷ 5 V

    Xover functions:
    (BAND Pass allowed)
    HIGH Pass & LOW Pass
    (20 ÷ 175 Hz) & (50 ÷ 30 0Hz)

    Filter slope - Filter "Q":
    ● 12 dB/oct - 0.7 (Stereo & Mono)

    Size:
    ● 590x200x50 mm

    Weight:

    ● 5,8 Kg

    Cliport Car Audio is an Authorized Dealer for products mosconi. For more info please visit:








    Cliport Car Audio Division
    Adress : Jl. Sumbawa No 60 (BANDUNG)
    Office Number : (022) 73404522
    Mobile : 081221420030

    Customer Support@Cliport Car Audio
    YM : cliportaudio_cs


  5. #4
    Kopral Satu
    Posts
    94
    Power
    M-Store Point
    0
    Online
    5 Days 17 Hrs 20 Mins 27 Secs

    Thumbs up

    Keren punya designnya...est harga di level brp ni boss? Thanksss

  6. #5
    Letnan Dua
    Location
    www.cliport-audio.com
    Posts
    1,211
    Power
    M-Store Point
    0
    Online
    1 Wk 3 Days 18 Hrs 45 Mins 39 Secs
    Barang masih belum masuk (OTW) untuk harga masih belum di tetapkan, yang jelas mendengar desas desus nya harga gak sampai 10jt mungkin <8jt. ditunggu saja pasti kita akan memberikan special gift untuk 10 pembeli pertama untuk member modkom

  7. #6
    Mayor
    Location
    JAKARTA
    Posts
    3,581
    Power
    37
    M-Store Point
    0
    Online
    1 Mth 3 Wks 3 Days 14 Hrs 10 Mins 35 Secs
    Kyknya muanteeep neh hehehe,naksir ama yg AS300.2 neh bro....kalo uda ada harganya tolong PM in yah! Thx..

  8. #7
    Letnan Kolonel
    Location
    klaten
    Posts
    6,539
    Power
    40
    M-Store Point
    0
    Online
    1 Mth 1 Wk 1 Day 1 Hr 40 Mins 16 Secs
    kayanya muanteb nih power nya......desain nya cakep...

  9. #8
    Letnan Kolonel
    Location
    Surabaya - Ambon
    Posts
    5,140
    Power
    32
    M-Store Point
    0
    Online
    1 Mth 3 Days 11 Hrs 55 Mins 51 Secs
    Quote Originally Posted by cliport View Post
    Barang masih belum masuk (OTW) untuk harga masih belum di tetapkan, yang jelas mendengar desas desus nya harga gak sampai 10jt mungkin <8jt. ditunggu saja pasti kita akan memberikan special gift untuk 10 pembeli pertama untuk member modkom
    lumayan juga harga nya.. sekelas arc se dong yah ?

  10. #9
    Mayor
    Location
    jkt
    Posts
    4,311
    Power
    38
    M-Store Point
    0
    Online
    2 Wks 2 Hrs 18 Mins 48 Secs
    Quote Originally Posted by mr.nice View Post
    Kyknya muanteeep neh hehehe,naksir ama yg AS300.2 neh bro....kalo uda ada harganya tolong PM in yah! Thx..
    wuuuiiiiiihhh ,,,, siap2 ngeborong neeeh,,
    buat angkat apa boosss,
    guede buanget tuhhh,,,,,,:eek:

  11. #10
    Honoured Member
    Posts
    4,601
    Power
    47
    M-Store Point
    0
    Online
    3 Wks 3 Days 3 Hrs 57 Mins 25 Secs

    Thumbs up

    Power mantab banget nich......
    Bro Cliport.....kapan-kapan kalau saya ke Bandung saya mau mampir ke sana yaa....

    Best Regards

    Wendo
